Nautor Swan 45 NO NAME

Boat Overview

Year: 2003

Model: Swan 45

Hull Number: #024

Name: NO NAME

This is the only Swan 45 currently on the brokerage market in the USA. The performance of the Swan 45 is extraordinary, particularly with the custom bow sprit that allows for larger asymmetric spinnakers.

This Swan 45 was originally owned by one of the principles of the famed Jamestown Boat Yard in Rhode Island. The next owner purchased her in 2012 and she was lightly sailed, mainly on Long Island Sound.

The present owner acquired her in 2021 and has been sailing her on the Chesapeake Bay and up to Maine during the summers only ever since.

The upkeep this Swan 45 has received by all three owners is exemplary, with new teak decks laid in about 2017 and a large inventory of sails (2 of them new in 2025).

This Swan 45 features the preferred 2 cabin, 2 head interior plan, and a beautiful varnished teak interior.

She is ready for racing or cruising.

Photos will be available as soon as she is commissioned this spring.

Hull

Cored fiberglass/vinylester hull topsides and solid fiberglass bottom.

Hull topsides painted blue Awlgrip.

Structural bulkheads are marine grade plywood.

Fin keel with "L" bulb.

Ability to add or remove up to 400kgs of ballast in the bulb as desired.

Spade rudder with carbon stock.

Upper and lower rudder bearings (replaced 2023).

Aluminum quadrant with Vectran steering cables.

Single gold sheer line stripe.

Double white waterline stripe.

Open transom.

Weed cutter top leading edge of rudder.

Deck

Sprint prepreg fiberglass decks with closed cell foam core.

Teak overlay on side decks and in cockpit (new about 2017).

Stainless-steel stem head fitting.

Stainless-steel bow rail.

Stainless-steel stern rail.

1 x 19 stainless-steel double lifelines.

Lifeline gate to starboard.

Anchor locker forward with deck access.

3 x opening deck hatches over forward cabin, forward head and saloon.

2 x pair fixed ports.

6 x opening ports, 4 in the coachroof and 2 in the cockpit.

Companionway with drop down self-stowing board.

Stainless-steel handrails on coach roof.

1 x pair jib tracks with line car pullers.

All lines from the mast run under deck to 2 x 4 gang line stoppers (new 2022 and 2023), 1 each side of companionway.

Cockpit locker starboard side seat.

Lazarette locker with access through cockpit floor aft.

Mainsheet track in cockpit floor with traveler control lines exiting at pedestal.

Single carbon wheel on pedestal.

Ocean 1 gypsy 12volt anchor windlass (not installed).

Various Wichard “D” hook padeyes located on deck.

Carbon radar antenna post aft with quick disconnect wiring.

Removable helm seat/locker aft.

Winches

All Harken, all serviced 2025

• 2 x B560 TCR primary.


• 2 x B480 TCR halyard.


• 2 x B56 3 speed, STR mainsheet.

General Arrangement

Accommodations

Sleeps 8. 2 in each of the 2 sleeping cabins, 2 on the single settees and 2 in the pilot bunks outboard of the settees. Hand rubbed, varnished teak interior. Teak and holly cabin sole. Vinyl overhead panels. 2 heads.

Forward Cabin

“V” berth in the bow. Single seat aft to starboard. Overhead lockers the length of each bunk, port and starboard. Hanging locker aft to starboard. Door closes off cabin making cabin en-suite with the head to port.

Forward Head

Located on the port side and aft of the “V” berth. White gel coated fiberglass unit to half height. Teak above. Jabsco manual head with holding tank. Sink with hot and cold pressure water. Telephone type shower. Lockers outboard as well as under sink. Mirror forward and on upper locker doors. Cup holders. Soap dish holder. Teak shower grate. Sump pump for shower tray. Exhaust fan.

Main Saloon

Located aft of the forward cabin. Table on centerline with leaves port and starboard. Batteries are stored in the center of the table. Single settee to port and starboard with lifting backrest each side to form a pilot bunk. Ultra leather tan upholstery, new in 2010. Lockers and shelving port and starboard behind each settee. The mast steps immediately forward of the table.

Navigation Station

Located aft of the saloon on the starboard side. Forward facing. Lifting desk lid for paper chart storage. Extra cabinetry to house the GPS unit. Drawers forward. Wet hanging locker aft. Surrounded by navigation and communication electronics as well as electrical panel.

Galley

Located on the port side aft of the saloon. “L” shaped. Double stainless-steel sink close to centerline. Force 10, 3 burner propane stove with oven outboard. Top loading freezer forward. Side loading fridge aft. Refrigeration driven by 12volt DC. Fridge and freezer compressors replaced (2024). Freezer cold plates replaced (2022). Lockers outboard as well as under the sinks. 2 foot pedals, 1 for sea water.

Aft Cabin

Located aft of the galley on the port side. Double “V” type berth. Lockers and hanging locker forward and outboard. Access to back end of engine under furniture in board.

Aft Head

Located aft of the navigation station and on the starboard side. White gel coated fiberglass unit to full height. Teak above. Jabsco manual head. Sink with hot and cold pressure water. Telephone type shower. Lockers outboard as well as under sink. Mirror on upper locker doors. Cup holders. Soap dish holder. Teak shower grate. Sump pump for shower tray. Exhaust fan.

Engine

Engine access is under the companionway steps.

Engine: Volvo Penta, D2-55, 53HP diesel engine.

Transmission: Saildrive transmission (rebuild 2021).

Saildrive Seal: (2021).

Propeller: 2 blade folding propeller.

Plumbing and Ventilation

Composite sea cocks for all through hull fittings below waterline (serviced 2023).

Drinking water purifier.

Hot and cold water deck shower in cockpit.

Foot pump for sea water in galley.

“Y” valve for forward head.

2 x manual bilge pumps.

1 x electric bilge pump (2024).

Raw water strainer (2021).

Raw water pump (2025).

Tank gauges for water and fuel.

Some hoses replaced (2021).

Portable air conditioner (2021).

Exhaust fans in galley and heads.

Engine space air intake and fan exhaust.

Remote control fire extinguisher in engine space.

Propane lines replaced (2021).

Propane tank (2021).

Propane alarm (2021).

Both heads replaced (2021).

Electrical

290Ah house battery bank located in vented box in dining table.

12volt 46Ah starting battery in same box.

115volt AC shore power with plug in cockpit.

12volt DC system.

Mass 12/80 battery charger (2023).

Mass 12/1200 Sine inverter with Masterlink MICC panel.

Mast base and shrouds grounded to keel.

12volt outlets at navigation station and helm station.

Main electrical switch panel at navigation station.

130Amp alternator with 3 step regulator for house batteries.

60Amp alternator for engine start battery.

Lighting upgraded to LED (2021).

Electronics

At Nav Station:

• Northstar 951X GPS in its own cabinet.


• B&G Hercules 2000 wind/speed/depth MFD.


• ICOM IC-M502 VHF.


• ICOM SP-24 speaker.


• ICOM IC-M802 SSB.


• Raytheon RL 70C Pathfinder plus radar.


• Fusion stereo with 2 cockpit speakers (2021).


• AIS (2025).

At Helm:

• B&G Hydra autopilot with hydraulic ram.


• Autopilot control replaced (2021).


• Radar antenna post.


• Suunto compass on pedestal.

Rigging

Carbon fiber 15/16ths mast.

Double swept back carbon spreaders.

Mast re-painted (2022).

Carbon fiber boom.

Dynema lazy jacks (2023).

Single line reefing for 2 reefs.

Double ended main sheet.

Main chain plates all the way outboard.

Navtec stainless-steel rod rigging (new 2022).

Carbon instrument bracket under goose neck.

Additional forestay with Tuff Luff for racing.

Carbon spinnaker pole with track on mast.

Spare spinnaker pole.

Carbon fiber bow sprit for asymmetric sails (re-painted 2024).

Reaching strut.

Harken roller furler for headsail.

Navtec hydraulic panel, 1 each side.

Hydraulics for backstay and mainsail outhaul.

Adjustable mast base.

Hydraulic jack for mast base to adjust rig tension.

Quick release for hydraulic backstay.

Running rigging replaced as needed including new jib halyard (2025), new fractional spinnaker halyard (2025) and new tack line (2025).

Sails

Working Sails:

• Quantum mainsail (2025).


• Quantum roller furling jib (2025).

Other Sails of Varying Condition:

• North 3DL mainsail.


• UK Dacron mainsail.


• UK storm trisail.


• Doyle Stratis jib.


• North light jib (2007).


• North M3 3DL jib.


• North #3 jib (2006).


• UK storm jib.


• UK #3 jib.


• UK jib top.


• North code 1A (2005).


• North code 2S 0.5oz spinnaker (2009).


• North code 2A spinnaker (2005).


• Doyle A2 spinnaker.


• UK A3 spinnaker.


• Doyle A3 spinnaker with sock.


• UK light asymmetric 4 spinnaker.


• UK S4 heavy.


• Code zero.


• Doyle spinnaker staysail.


• 2 x spinnaker sock with snuffer.

Additional Equipment

• Achilles LSR-290E dinghy (2021).


• Cockpit table including padded storage bag.


• Cockpit dodger.


• Cockpit cushions.


• Mosquito screen drop board for companionway.


• Aluminum bar in anchor locker and cockpit locker to stow running rigging.


• 8 x man Revere Regatta life raft in valise (2021).


• Gale rider.


• Safety equipment for Cat 1 offshore racing.


• Nautor, ships manuals.


• Trailer for hauling yacht’s gear.


• Light weight emergency tiller.


• Winch covers (2025).


• Pain and Wessex flares (2025).


• Magma BBQ grill on stern rail (used twice).


• Fire extinguisher and suppression system serviced (2025).


• MOM (serviced 2025).
